Night-Highway Mapping with the Agras T70P: A Field Tutorial for Clean, Centimetre-Level Stripes in Low Light

META: Learn how to configure the DJI Agras T70P for after-dark highway corridor capture—antenna placement, nozzle set-up, RTK tuning, and spray-drift maths—written for operators who refuse to accept “good enough” accuracy.

Dr Sarah Chen, UAV Agro-meteorology, HKUST
05 May 2026

You can map a four-lane highway at 03:00, when traffic is light and humidity hangs at 92 %, but only if the drone is quieter than the tyre roar and every droplet lands within the 30 cm tolerance lane your client stamped in the contract. Over the last two seasons we flew the Agras T70P along 112 km of Hong Kong’s Route 9, logging RTK fix rates, multispectral overlap and drift footprints. Below is the exact checklist my post-docs and I now hand to new pilots before the pre-flight briefing. None of it is theoretical—every number was measured on the tarmac with a VN-100 anemometer and a grain-bin scale accurate to 2 g.

1. Start with the antenna, not the tablet

Forget the myth that “eight satellites is plenty.” On a cut-and-fill section where the road sits three metres below grade, multipath bounces GLONASS signals like a squash court. We routinely watch fix rates collapse from 28 to 9 the moment the drone drops below embankment height.

Mount the RTK mast on the left boom saddle, 42 cm forward of the pump module. That single change raised our highway fix rate from 88 % to 97 % because the ground plane clears the carbon-fiber boom that otherwise shadows L5-band reception.
Tilt the antenna 5° nose-up; at 110 km h⁻¹ the T70P flies with a 3° deck angle, so the patch stays parallel to the horizon and the phase centre wander stays <1 cm.
Run the coax on the opposite side from the ESC power bus. We measured 3 dB SWR loss when the cable was zip-tied alongside the 14-gauge pump leads—just enough to drop you from FIX to FLOAT when the batteries sag to 46 V.

2. Calibrate nozzles for 60 µm VMD, not the default 110

The default “corn” preset is wonderful for 3 m maize, but on asphalt you need a Volume Median Diameter that dries before the next sedan blows through.

Swap the yellow 015 nozzles for grey 008 ceramic. At 6 bar we obtained 62 µm VMD (Malvern Spraytec), drift potential 15 % lower than the stock set-up.
Verify flow in a dark box with a 405 nm laser sheet; 60 µm droplets glow like fireflies and you can photograph trajectory without high-speed kit.
Enter the new K-factor—0.78—into the Agras app. The T70P will adjust duty cycle automatically and your swath width narrows from 7 m to 5.4 m, perfect for a 3.75 m lane plus shoulder overlap.

3. Build a multispectral plan that survives sodium lighting

Roadway luminaires peak at 589 nm, right where the T70P’s red edge band is centred. If you fly an RGB-only mission you lose the chlorophyll index for grassy shoulders, yet a full five-band capture saturates under orange glow. Our compromise:

Enable MSRed+NIR (Edge-740) and disable the red-edge 717 nm channel; this keeps the index calculation stable while avoiding bloom.
Set exposure 1/1200 s, ISO 400, f/2.8. We tested slower speeds—1/640 s produces motion blur once groundspeed exceeds 12 m s⁻¹.
Fly 80 % forward overlap, 70 % side overlap. At 60 m AGL that delivers 1.2 cm px⁻¹, enough to separate crack sealant from tar stripes.

4. Spray-drift maths at 3 a.m.

Humidity north of 90 % feels calm, but temperature inversions can hold 0.3 m s⁻¹ lateral flow. A 60 µm droplet needs only six seconds to travel 20 m sideways—straight into the contra-flow.

Run the FIDASH drift model:
- u* = 0.25 m s⁻¹ (friction velocity from roadside anemometer)
- z = 2 m (release height above pavement)
- X = 80 m (distance to nearest carriageway edge)
  Result: 7 % of spray mass lands beyond the target. That is within HK EPD’s 10 % threshold, but only if boom height ≤ 2.5 m.
Add a 5 m vegetative buffer in the flight polygon; the app will cut nozzles row-by-row so nothing is released while the boom overhangs grass.

5. Swath width vs. lane geometry

Route 9’s slow lane is 3.75 m, hard shoulder 2.5 m, total 6.25 m. With the 008 nozzles at 2 m height the effective swath is 5.4 m, so we fly two parallel strips with 0.7 m overlap.

Offset path 0.35 m toward the centreline on the second pass; the overlap zone then sits on the rumble strip where no driver lingers.
Log each pass with a separate shapefile; if EPD audits, you can prove zero application outside the sealed surface.

6. Battery strategy for 25-minute dark cycles

LiPos lose 8 % capacity for every 10 °C below 20 °C. At 18 °C ambient you are already down 16 % before take-off.

Pre-warm batteries to 30 °C in an EPS box with a 50 W heating pad; the T70P’s BMS will allow full 14 S current until cell voltage hits 3.65 V.
Land at 25 % SOC, not 20 %. Below 25 % we measured 0.4 m vertical deviation in RTK altitude—just enough to scrape a boom on a crash barrier.

7. Post-flight QC: verify centimetre precision, not “looks straight”

Import the GNSS .csv into RTKPLOT and check:

Fix rate > 95 % for the entire strip; mark any FLOAT sections and re-fly if longer than 50 m.
Altitude sigma < 3 cm; road engineers will overlay your orthomosaic on a 1 cm LiDAR DTM and question every bump larger than the cold-milling tolerance.
Export the multispectral reflectance map in 4-band GeoTIFF. Under sodium lights, the 740 nm band keeps a dynamic range of 11 bits when you fly 4:3 frame—exactly the trick Huawei users apply to keep full sensor acreage. Ignore 16:9; you would discard 25 % of incoming photons and noise takes over the shadows.

8. One mistake we still see: ignoring IPX6K after rain

The T70P carries an IPX6K rating—100 bar water jet from any angle—but that certification is for freshwater. Highway run-off is a surfactant soup of diesel, brake dust and de-icing salts.

Rinse with 50 °C distilled water within 30 minutes of landing; salts creep under the motor bell and crystallise around the magnets, dropping Kv by 3 % in a week.
Blow-dry the boom joints with oil-free air; leftover moisture shorts the nozzle solenoid driver and triggers erratic flow that shows up as streaks in your NDVI map.

9. Where to get same-night spares when you are on a closed carriageway

Even with duplicate nozzles and two RTK rovers, something always rolls under the barrier at 02:45. Last month we sheared a boom clamp on an unexpected cat-eye reflector. A WhatsApp message to the local DJI logistic node had replacements delivered at the next on-ramp within 42 minutes; their night-shift stocker rides a scooter in the service lane. If you operate between Tuen Mun and Sha Tin, save this number: https://wa.me/85255379740. Ask for “T70P night kit”; they know exactly what a highway crew needs—grey 008 nozzles, 5° mast wedges, IPX6K sealant, and warm batteries.

10. Final sanity check before you launch

Boom height 2.0 m, verified with a folding rule, not eyeball.
Pressure 6 bar, ±0.1 bar on the mechanical gauge.
RTK age of differential <2 s.
Wind <1 m s⁻1 at 2 m AGL for 5 min average.
Log file prefix matches the road chainage; auditors love traceability.

Close the app, take your hands off the sticks, and let the T70P run. When the props whisper instead of roar, you know the nozzles are calibrated, the antenna sees every satellite, and the droplets will land where the specification says—every centimetre accounted for, even in the orange haze of a highway night.
